COMFORT
MAXI
The largest in the range
Very versatile pump, perfect
for both domestic and public pools.
The MAXI series pumps meet the highest pumping requirements in medium and large pools.
Features
- Self-priming up to 2mwh
- Suitable for operation with salt chlorinators and sea water
- High efficiency motors class IE2 and IE3 according to regulation (EU) 2019/1781
- Thermal protector incorporated in single-phase version
- Insulation Class: F
- Protection: IP55
- Motor: 50Hz/2900 rpm also available at 60Hz
- Motor painting by cataphoresis
- Tmax: 40ºC
Materials
- Pump housing: Polypropylene + 30% GF
- Impeller and Diffuser: PPO + 30% GF
- Shaft: Stainless steel AISI 316
- Mechanical Seal: Carbon + Resin – Ceramics
- Pre-filter cover: SAN
- Pre-filter basket: Polypropylene +20% GF
Downloads
|
Type
|
Power
|
Cond.
µF |
IE2
|
IE3
|
Head (m)
|
Connections
|
Weight Kg
|
||||||||||
|
III
230V A |
III
230V A |
III
400V A |
4 | 6 | 8 | 10 | 12 | 14 | 16 | 18 |
DN
|
||||||
|
Flow rate (m³/h)
|
|||||||||||||||||
| kW | HP | IN | OUT | ||||||||||||||
| MAXI-15 | 1,1 | 1,5 | 30 | 6,0 | 4,0 | 2,3 | 34,6 | 29,4 | 23,3 | 16,8 | 11,1 | 3,3 | – | – | Ø 75 | Ø 75 | 17,0 |
| MAXI-20 | 1,5 | 2 | 40 | 8,0 | 5,4 | 3,1 | 44,7 | 39,8 | 33,7 | 27,6 | 21,0 | 12,0 | 4,5 | – | Ø 75 | Ø 75 | 19,0 |
| MAXI-30 | 2,2 | 3 | 2×30 | 11,7 | 7,6 | 4,4 | – | 53,7 | 47,2 | 38,8 | 28,2 | 16,0 | – | – | Ø 75 | Ø 75 | 20,0 |
| MAXI-40 | 3 | 4 | – | – | 9,9 | 5,7 | – | 62,3 | 58,1 | 52,2 | 45,2 | 37,1 | 26,5 | 7,4 | Ø 75 | Ø 75 | 24,0 |
